Foldable Container Houses

size:	Standard Folding Container	W2990 x D2896 x H6055 mm	Export Folding Container	W2500 x D2500 x H5900 mm
Area	28.05 ㎡	Capacity	2 people	Weight:1.25T

Note: The rendering is for reference only, and this price is the EXW price.

NO.	Item Name	Components & Specifications
1	Top Frame	1. Galvanized steel beam, 180mm width 2. 4 pcs heavy‑duty export galvanized corner fittings 210150210 3. Purlin: 40601.2 square tube; color steel sheet 0.42 mm, butyl rubber waterproof seal for whole roof 4. Insulation: 50 mm glass wool, density ≥14 kg/m³, Class A non‑combustible. 831 ceiling panel 0.35 mm. Full‑360° no‑dead‑angle spray painting.
2	Bottom Frame	1. Galvanized steel beam, 160mm width pull beam 2. 4 pcs heavy‑duty export galvanized corner fittings 210150160 3. 9 pcs 50*100 square tube. Anti‑rust paint covers all cutting, welding & drill holes. Full‑360° no‑dead‑angle spray painting.
3	Vertical Column	4 pcs galvanized steel 210150. Include connection plates & M1230 galvanized inner hex bolts for box‑to‑box assembly.
4	Base	0.7 mm thick flashing sheet
5	Floor Board	5 pcs calcium silicate board (asbestos‑free)
6	Door	Mid‑grade steel door (970*1970), flat door frame, AB lock, 50mm wall panel
7	Window	Plastic‑steel window B: 3.0 mm hollow glass, anti‑theft grill + screen mesh, size 930*1130 mm, 2 units, match 50mm wall panel
8	Wall Panel	Width 950 mm, 50 mm sandwich panel. Outer & inner skin: 0.29 mm orange‑peel texture steel sheet with PE coating. Insulation: rock wool density ≥70 kg/m³.
9	Wall Panel Trim	Export‑type U‑shaped color steel trim for wall panels
10	Downpipe	Φ50 mm PVC downpipe, 4 pcs
11	Ceiling Edge Trim	4*4 type 831 ceiling matching trim parts
12	Column Inner Corner	4 pcs column inner corner trim
13	Auxiliary Fittings	3 pcs 995 structural glue; 80 pcs 420 pan head self‑drilling screws; 60 pcs 1275/12100 hex self‑drilling screws; 2 pcs 12100 hex self‑drilling screws; 6 pcs 1275 hex self‑drilling screws; 45 pcs 1225 hex self‑drilling screws; 32 pcs 4*25 self‑tapping screws; 1 set connecting bolts.
14	Floor Surface	1.0 mm welded‑seam vinyl floor sheet
15	GB Standard Electrical Configuration	Brand electric accessories, incoming‑line cable 6 mm², 4 mm², 2.5 mm²,1.5 mm² (2‑core for lamp circuit). 1×3‑hole socket 3×5‑hole sockets 1×single‑pole switch 2×long strip lamps 1×high‑grade 8‑way distribution box 1×2P‑32A earth‑leakage circuit breaker
